Shorten URL

Shorten URL - Modular Laravel Monolith

Client workspace · Group-based RBAC · Redirect expiry and click tracking

Role: Solo developer. I designed the modular architecture, validation rules, and deployment flow.

Laravel 10 · PHP 8.1 · MySQL 8 · Blade · AdminLTE 3 · Docker Compose · Nginx · spatie/laravel-permission · nwidart/laravel-modules

View Source Code

This project separates one Laravel application into three clear surfaces: public redirects, admin back office, and a client-facing workspace. The goal was not CRUD alone, but putting business rules such as RBAC, per-user uniqueness, and redirect expiry into the correct layers.

System Architecture

flowchart LR
    U[User / Admin / Visitor] --> N[Nginx]
    N --> L[Laravel App]
    L --> A[Auth Module]
    L --> C[Client Module]
    L --> D[Dashboard + Admin Modules]
    L --> X[Access Module]
    C --> URL[Url Module]
    C --> TAG[Tag Module]
    D --> G[Group Module]
    D --> USER[User Module]
    G --> P[Role / Permission Layer]
    USER --> P
    URL --> DB[(MySQL)]
    TAG --> DB
    G --> DB
    USER --> DB
    X --> URL

I chose a modular monolith because the domains are tightly coupled. Shared auth context, one runtime, and one database made more sense than splitting the application into multiple services at this scale.

End-to-end Link Workspace

Problem: A useful URL shortener needs more than a create form. Users want filtering, custom aliases, tags, archived states, detail views, and batch-like management without bouncing through multiple screens.

Solution: Build a dedicated client workspace while reusing the same domain logic as the admin surface.

Implementation highlights:

• Client routes live under a dedicated namespace to keep boundaries clear
• Create, update, archive, delete, and tag management delegate to the same controllers and repositories used elsewhere
• Validation rules encode global and per-user uniqueness constraints
• Repository methods hydrate tag relationships so edit forms can be prefixed correctly

Result: Users get a focused workspace while the business rules remain centralized instead of drifting between admin and client implementations.

sequenceDiagram
    actor User
    participant UI as Client Links UI
    participant CC as ClientController
    participant UC as UrlController
    participant VR as UrlRequest
    participant UR as UrlRepository
    participant TR as TagRepository
    participant DB as MySQL

    User->>UI: Create or edit short link
    UI->>CC: POST/PATCH /trang-ca-nhan/links
    CC->>UC: Delegate action
    UC->>VR: Validate rule by user
    VR-->>UC: Valid data
    UC->>UR: create/update URL
    UC->>TR: fetch related tags
    UC->>UR: attach/sync url_tag
    UR->>DB: persist URL + pivot
    DB-->>UI: success + updated state

RBAC by Group and Permission Matrix

Problem: The admin surface spans many resources and actions, and hard-coded roles on the user record are too rigid once groups and permission editing enter the picture.

Solution: Map business groups to roles, seed permission matrices by module/action, and let the admin surface edit those permissions safely.

Implementation highlights:

• Seeder-driven permission generation by module and action
• Each business group owns a role mapping
• User updates sync group membership and the assigned role together
• Route middleware blocks regular users from the admin namespace before controller logic runs
• Permission forms load and sync the full matrix through Spatie permissions

Result: The authorization model scales with the product instead of remaining a fragile collection of if-statements.

sequenceDiagram
    actor Admin
    participant UI as Admin Permission UI
    participant GC as GroupController
    participant ROLE as Spatie Role
    participant MOD as modules table
    participant DB as MySQL

    Admin->>UI: Open group permissions
    UI->>GC: GET /quan-tri-vien/group/{id}/permission
    GC->>ROLE: load role + permissions
    GC->>MOD: load module metadata
    MOD->>DB: query modules
    ROLE->>DB: query permissions
    DB-->>UI: render permission matrix
    Admin->>UI: Submit new permissions
    UI->>GC: PUT permission-handle
    GC->>ROLE: syncPermissions()
    ROLE->>DB: update role_has_permissions
    DB-->>UI: success flash message

Public Redirect with Expiry and Click Tracking

Problem: A redirect endpoint that only looks up a record and forwards the request misses business meaning. Expired links, missing links, and click tracking all need explicit behavior.

Solution: Treat public redirect as a first-class access flow with HTTP semantics and state mutation.

Implementation highlights:

• Catch-all route reserved for short codes only
• Access controller performs the lookup and decides between 404 and 410
• Successful access increments clicks and extends expiry where the product requires it
• Redirect logic stays small, but the surrounding validation and state rules remain explicit

Result: Redirects become observable business behavior rather than anonymous helper logic.

CI/CD & Deploy

• Docker Compose for both local and production variants
• Separate deployment files for production and CI-driven delivery
• HTTPS-aware configuration and explicit routing boundaries so catch-all redirects stay safe
